>> Product Advantage
1. High Strength and Load-Bearing Capacity
L-angle steel offers excellent structural support for heavy-duty applications. Its L-shaped design distributes load efficiently.
2. Corrosion Resistance and Durability
Galvanized or coated angle steel withstands harsh environments, ensuring long-term use.
3. Versatile Applications
Angle steel is suitable for construction, machinery, shelving, and industrial structures.
4. Easy Installation and Fabrication
Its uniform L-shape allows precise cutting, welding, and assembly for flexible design.
5. Cost-Effective Structural Solution
Provides strength without excessive material weight, lowering project costs while maintaining stability.
>> Technical Parameters
| Material | Q195 / Q235 / Q345 / Galvanized Steel | Surface Treatment | Hot-dip Galvanized / Pre-galvanized / Painted |
| Leg Length (A × B) | 20×20 mm - 200×200 mm | Thickness (t) | 2 - 20 mm |
| Length | 6m / 9m / 12m or Customized | Processing Method | Hot Rolled / Cold Rolled |
| Hole Type | With or Without Punching | Weight | 1 - 50 kg/m (depending on size) |
>> Product Uses
1. Construction and Building Frames
Used as structural supports, bracing, and frameworks in buildings and industrial facilities.
2. Machinery and Equipment Support
Provides strong, durable frameworks for machinery, equipment, and manufacturing structures.
3. Shelving and Storage Systems
Commonly used for storage racks, shelving units, and warehouse organization.
4. Greenhouse and Agricultural Structures
Acts as a primary or secondary support in greenhouses and farming frameworks.
5. Infrastructure and Utility Applications
Applied in guardrails, brackets, and utility supports requiring stability and strength.
>> FAQ
Q1. What is the difference between galvanized aluminum magnesium steel and ordinary galvanized steel?
A: Aluminum magnesium coating significantly improves corrosion resistance, especially suitable for high salt spray and acid rain areas, with a lifespan extension of more than 50%
Q2. Does the bracket require additional anti-corrosion treatment?
A: No need! The coating and passivation treatment have been completed before leaving the factory, and it can be used directly.
Q3. Can you provide a load-bearing calculation report?
A: We can provide third-party inspection reports along with the goods and support customized wind/snow load analysis for the project.
Q4. Do you accept sample orders?
A: Support! 3 sets minimum order, shipped within 7 days, sample fee can be deducted from bulk order.
Q5. Payment method and warranty period?
A: Accept TT/LC, with a 15 year warranty (free replacement for non-human damage.)
